MC56F84789VLL
256KB 256K x 8 FLASH 56800EX 32-Bit Microcontroller 56F8xxx Series MC56F847 3.3V 100-LQFP
- Manufacturer: NXP USA Inc.
- NO: 318-MC56F84789VLL
- Package: 100-LQFP
- Datasheet:
- Stock: 900
- Description: 256KB 256K x 8 FLASH 56800EX 32-Bit Microcontroller 56F8xxx Series MC56F847 3.3V 100-LQFP (Kg)
- Delivery:
- Payment:
In Stock
Please send RFQ , we will respond immediately.
.png)
.png)
.png)
.png)
.png)
.png)
.png)
.png)
.png)
You may place an order without registering to Chip Smart.
We strongly suggest you sign in before purchasing as you
can track your order in real time.
For your convenience, we accept multiple payment methods in USD, including PayPal, Credit Card, and wire transfer.
RFQ (Request for Quotations)It is recommended to request for quotations to get the latest
prices and inventories about the part.
Our sales will reply to
your request by email within 24 hours.
1. You'll receive an order information email in your inbox.
(Please remember to check the spam folder if you didn't hear from us).
2. Since inventories and prices may fluctuate to some
extent, the sales manager is going to reconfirm the order and let you know if there
are any updates.
Shipping starts at $40, but some countries will exceed $40. For
example (South Africa, Brazil, India, Pakistan, Israel, etc.)
The basic freight (for package ≤0.5kg or corresponding volume) depends on the time
zone and country.
Currently, our products are shipped through DHL, FedEx, SF, and UPS.
Delivery TimeOnce the goods are shipped, estimated delivery time depends on the shipping methods you chose:
FedEx International, 5-7 business days.
The following are some common countries' logistic time.
| Parameters | |
|---|---|
| Part Status | Active |
| Series | 56F8xxx |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C~105°C TA |
| Packaging | Tray |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| Technology | CMOS |
| RoHS Status | ROHS3 Compliant |
| Published | 2002 |
| Package / Case | 100-LQFP |
| Number of Terminations | 100 |
| Factory Lead Time | 13 Weeks |
| ECCN Code | 3A991.A.2 |
| HTS Code | 8542.31.00.01 |
| JESD-609 Code | e3 |
| Terminal Finish | Matte Tin (Sn) |
| Surface Mount | YES |
| Terminal Position | QUAD |
| Terminal Form | GULL WING |
| Peak Reflow Temperature (Cel) | 260 |
| Supply Voltage | 3.3V |
| Terminal Pitch | 0.5mm |
| Base Part Number | MC56F847 |
| Supply Voltage-Max (Vsup) | 3.6V |
| Supply Voltage-Min (Vsup) | 2.7V |
| Time@Peak Reflow Temperature-Max (s) | 40 |
| Subcategory | Microcontrollers |
| Power Supplies | 3/3.3V |
| Supply Current-Max | 101mA |
| Qualification Status | Not Qualified |
| JESD-30 Code | R-PQFP-G100 |
| Oscillator Type | Internal |
| Number of I/O | 86 |
| Peripherals | Brown-out Detect/Reset, DMA, LVD, POR, PWM, WDT |
| RAM Size | 32K x 8 |
| Speed | 100MHz |
| uPs/uCs/Peripheral ICs Type | MICROCONTROLLER |
| Bit Size | 32 |
| Has ADC | YES |
| DMA Channels | YES |
| PWM Channels | YES |
| DAC Channels | YES |
| ROM (words) | 262144 |
| Clock Frequency | 50MHz |
| Core Processor | 56800EX |
| Voltage - Supply (Vcc/Vdd) | 3V~3.6V |
| Program Memory Type | FLASH |
| Core Size | 32-Bit |
| Program Memory Size | 256KB 256K x 8 |
| Connectivity | CANbus, I2C, LINbus, SCI, SPI |
| Data Converter | A/D 16x12b, 16x16b; D/A 1x12b |
| EEPROM Size | 2K x 8 |
MC56F84789VLL Description
MC56F84789VLL microcontroller features several devices featuring peripheral sets targeted for a large number of applications. MC56F84789VLL datasheet is an excellent option for a variety of extensive hardware and software ecosystem. NXP USA Inc. MC56F84789VLL is suitable for Motion Control and Robotics, Gas Meter, Smart Power Socket and Light Switch, Motor Drives, and Electricity Grid and Distribution.
MC56F84789VLL Features
Independent-clocked COP guards
Bit manipulation engine
High-speed comparator
Real-time clock with calendar
Single-cycle fast I/O access port
MC56F84789VLL Applications
Motion Control and Robotics
Gas Meter
Smart Power Socket and Light Switch
Motor Drives
Electricity Grid and Distribution
